Introduction
Forged steel butt weld end gate valve is a kind of most common open/close valve. It is mainly composed of valve body, disc, bonnet, valve gland, gasket, bolt and nut. This forged steel gate valve uses disc to connect or cut off medium in pipeline. Disc functions like a sluice gate to connect or cut off media, so it is called gate valve or sluice valve. The on-off component of gate valve is valve disc. The movement direction of disc is perpendicular to the flowing direction of fluid. Gate valve can only be opened or closed fully. Butt weld end gate valve can be widely applied as fluid regulating and intercepting equipment in various pipelines, such as tap water, sewage, construction, petroleum, chemical, food, medicine, textile, electric power, shipbuilding, metallurgy, and energy pipeline systems.
Classification
Forged steel threaded gate valve can be widely applied as fluid regulating and intercepting equipment in various pipelines, such as tap water, sewage, construction, petroleum, chemical, food, medicine, textile, electric power, shipbuilding, metallurgy, and energy pipeline systems.
Advantages of Forged Steel Butt Weld End Gate Valve
1. Sealing materials we applied to manufacturer forged steel gate valve are wear resistant.
2. Valve seat is replaceable, which makes maintenance more simple and convenient.
3. Twice shot blasting processing makes the forged steel valve look fine and smooth.
4. Numerical control processing is utilized on valve disc.
5. Valve body adopts precision casting technique.
6. Small torsion is needed to open butt weld end gate valve.
7. Lifelong technology service is provided for all our products.
8. Guarantee period of our products is 18 months.
Pressure: CLASS900~2500 PN16.0~42.0
1. Welded Bonnet/Pressure Sealed Bonnet
2. Reduced Port
3. Solid Wedge Gate
4. Flange Ends/Butt-Welding Ends
Technical Specification of Forged Steel Gate Valve
|
Technical Specification
|
ASME/API
|
GB/JB
|
|
Design Standard
|
ASME B16.34/API600
|
GB/T12234 GB/T12224
|
|
Pressure-Temperature Rating
|
ASME B16.34
|
GB/T12224
|
|
Face-Face
|
ASME B16.10
|
GB/T12221 JB/T97-95
|
|
Flange Ends
|
ASME B16.5
|
GB/T9113JB/T82.1~82.4
|
|
Buttwelding Ends
|
ASME B16.25
|
GB/T12224
|
|
Inspection & Test
|
API598
|
JB/T9092
|
Material List for Main Parts of Butt Weld End Gate Valve
|
No.
|
Part Name
|
ASTM
|
|
Carbon Steel
|
Tailess Steel
|
Alloy Steel
|
|
1
|
Body
|
A105
|
LF2/LF3
|
A182 F304
|
A182 F11/F22
|
|
2
|
Seat
|
A182F6a
|
A182F6a
|
A182 F304
|
A182 F11/F22
|
|
3
|
Wedge
|
A182F6a
|
A182F6a
|
A182 F304
|
A182F6a
|
|
4
|
Stem
|
A276-410
|
A276-410
|
A276-304
|
A276-410
|
|
5
|
Gasket
|
Graphite+304
|
|
6
|
Sealing Ring
|
Graphite
|
|
7
|
Yoke
|
A216-WCB
|
A216-WCB
|
A351 CF8
|
A216-WCB
|
|
8
|
Bonnet
|
A105
|
LF2/LF3
|
A182 F304
|
A182 F11/F22
|
|
9
|
Bolt
|
A193 B7
|
A320L7
|
A193 B8
|
A193 B16
|
|
10
|
Packing
|
Graphite
|
|
11
|
Stem Bushing
|
A276-410
|
A276-410
|
A276-304
|
A276-410
|
|
12
|
Gland
|
A216-WCB
|
A216-WCB
|
A351 CF8
|
A216-WCB
|
|
13
|
Eye Blot
|
A193 B7
|
A320 L7
|
A193 B8
|
A193 B7
|
|
14
|
Stem Nut
|
A276-410
|
|
15
|
Hand Wheel
|
A197 or A47-32510
|
Main Dimensions & Weight
|
Pressure
|
Size
|
Main Dimension of Butt Weld End Gate Valve
|
|
Weight(kg)
|
|
mm
|
in.
|
d
|
LRF
|
LBW
|
LRTJ
|
H
|
W
|
|
WB
|
PB
|
WB
|
PB
|
|
CLASS900 PN16.0
|
15
|
1/2
|
10
|
216
|
216
|
216
|
197
|
321
|
180
|
9.8
|
11.5
|
|
20
|
3/4
|
13
|
229
|
229
|
229
|
211
|
321
|
180
|
9.7
|
11.2
|
|
25
|
1
|
19
|
254
|
254
|
254
|
238
|
321
|
180
|
9.5
|
10.8
|
|
32
|
1-1/4
|
24
|
279
|
279
|
279
|
257
|
380
|
200
|
17.5
|
18
|
|
40
|
1-1/2
|
40
|
305
|
305
|
305
|
276
|
414
|
200
|
21.6
|
22
|
|
50
|
2
|
50
|
368
|
368
|
371
|
320
|
502
|
300
|
42.7
|
44
|
|
CLASS1500 PN26.0
|
15
|
1/2
|
10
|
216
|
216
|
216
|
197
|
321
|
180
|
9.8
|
11.5
|
|
20
|
3/4
|
13
|
229
|
229
|
229
|
211
|
321
|
180
|
9.7
|
11.2
|
|
25
|
1
|
19
|
254
|
254
|
254
|
238
|
321
|
180
|
9.5
|
10.8
|
|
32
|
1-1/4
|
24
|
279
|
279
|
279
|
257
|
380
|
200
|
17.5
|
18
|
|
40
|
1-1/2
|
40
|
305
|
305
|
305
|
276
|
414
|
200
|
21.6
|
22
|
|
50
|
2
|
50
|
368
|
368
|
371
|
320
|
502
|
300
|
42.7
|
44
|
|
CLASS2500 PN42.0
|
15
|
1/2
|
10
|
264
|
264
|
264
|
197
|
321
|
180
|
12.3
|
13
|
|
20
|
3/4
|
13
|
273
|
273
|
273
|
211
|
321
|
180
|
12.1
|
12.7
|
|
25
|
1
|
19
|
308
|
308
|
308
|
238
|
321
|
180
|
11.8
|
12.5
|
|
32
|
1-1/4
|
24
|
349
|
349
|
352.2
|
257
|
380
|
200
|
20.9
|
21.8
|
|
40
|
1-1/2
|
40
|
384
|
384
|
387.2
|
276
|
414
|
200
|
27.5
|
29.3
|
|
50
|
2
|
50
|
451
|
451
|
454.2
|
320
|
502
|
300
|
53.3
|
55.4
|
Note: H means the height when valve is fully opened.
Maintenance of Butt Weld End Gate Valve
1. Hand wheel, handle and transmission mechanism are not allowed for lifting things. Collision of them is strictly prohibited.
2. Please open the bypass valve in advance before opening the valve to balance the pressure differential and to decrease opening force.
3. If the valve opens and closes frequently, please lubricate it regularly (at least one time every month).
4. The valve for long-term storage should be checked regularly. The surface of the valve must be clear of dirt and coated with anti-rust oil.
Payment, Package and Delivery
1. Products can be paid by T/T, D/P, D/A, L/C or according to your requirement.
2. Forged steel butt weld end gate valves are packaged by standard exported wooden cases.
3. Our forged steel gate valves are transported by sea, railway or air.
